Shop

U-Value Kit

gSKIN® KIT-2615C
1 Heat Flux (30mm x 30mm)
2 Temperatures

Features

  • – Calibrated Plug-and-Play solution
  • – Measurement of U-value (W/(m²K)), heat flux (W/m²), and 2 temperatures (°C)
  • – Compatible with standards ISO 9869 and ASTM C1046 /ASTM C1155
  • – Stores up to 2 million data points
  • – Battery lifetime >1 month
  • – High sensitive thermal detectors
  • – Read-out software included
  • – Compact design
  • – USB interface
  • – Comes with MOUNT-1214 (3 x thermal conductive pad)



Für U-Wert Messgeräte bzgl. der Schimmelanalyse (Deutschland oder Österreich) wenden Sie sich bitte an SchimmelProtektor.

Downloads
gSKIN® U-Value Kit Datasheet
gSKIN® U-Wert Kit Datenblatt
gSKIN® U-Value Kit Instruction Manual
gSKIN® U-Wert Kit Gebrauchsanleitung Deutsch
Software for U-Value Kit



Product gSKIN® KIT-2615C (calibrated)
Article Number A-163479
gSKIN® KIT includes a Sensor: gSKIN®-XO 67 7C (30mm x 30mm)
Logger: gSKIN® DLOG-4231
Mounting Tape
Heat Flux Range Min / Max [W/m²] ±300
Heat Flux Resolution [W/m²] <0.22
Min. Sensor Sensitivity b (S) [µV/(W/m²)] 7.0
Temperature Accuracy [°C] ±0.5 (-10…+46 °C)
±2.0 (-55…+125 °C)
Logger Dimensions (l x w x h) [mm x mm x mm] 52 x 20 x 15
Measurement Frequency 50/s to 2/d
Bit Resolution [bits] 12
Data Storage Capacity [# measurements] >2’000’000
Battery Lifetime c [days] >30 (rechargeable)
Computer Interface USB
Software
Installation – SW sent by email / via download link
Operating System Windows 2000 / XP / Vista / 7 / 8
Operation Modes Autonomous / Button Triggered / Live
Operating Temperature Range Min/Max [°C] -40 / 100 (-25 / 65 for Logger)
Calibration Temperature Range Min/Max [°C] -30 / 70
Calibration Accuracy b [±%] 3
Temperature Sensor 1 / 2 Cable Length [m] 5.0 / 1.0
Heat Flux Sensor Cable Length [m] 1.5 (with connector)

a For more details consult the datasheets of the individual products.
b Sensor calibration data already loaded onto logger for simple and fast plug-and-play measurements.
c At lowest measurement frequency (2/d).

If you are interested to purchase in larger quantities, please contact info@greenTEG.com

Price: CHF 1.637,70

More Details
Loading Updating cart…

Rent a U-Value Kit

gSKIN® KIT-2615C
1 Heat Flux (30mm x 30mm)
2 Temperatures
Renting an U-Value Kit is currently only possible for customers in Switzerland

Features

  • – Calibrated Plug-and-Play solution
  • – Measurement of U-value (W/(m²K)), heat flux (W/m²), and 2 temperatures (°C)
  • – Compatible with standards ISO 9869 and ASTM C1046 /ASTM C1155
  • – Stores up to 2 million data points
  • – Battery lifetime >1 month
  • – High sensitive thermal detectors
  • – Read-out software included
  • – Compact design
  • – USB interface
  • – Comes with MOUNT-1214 (3 x thermal conductive pad)



Downloads
gSKIN® U-Value Kit Datasheet
gSKIN® U-Wert Kit Datenblatt
gSKIN® U-Value Kit Instruction Manual
gSKIN® U-Wert Kit Gebrauchsanleitung Deutsch
Software for U-Value Kit



Product gSKIN® KIT-2615C (calibrated)
Article Number A-163482
gSKIN® KIT includes a Sensor: gSKIN®-XO 67 7C (30mm x 30mm)
Logger: gSKIN® DLOG-4231
Mounting Tape
Heat Flux Range Min / Max [W/m²] ±300
Heat Flux Resolution [W/m²] <0.22
Min. Sensor Sensitivity b (S) [µV/(W/m²)] 7.0
Temperature Accuracy [°C] ±0.5 (-10…+46 °C)
±2.0 (-55…+125 °C)
Logger Dimensions (l x w x h) [mm x mm x mm] 52 x 20 x 15
Measurement Frequency 50/s to 2/d
Bit Resolution [bits] 12
Data Storage Capacity [# measurements] >2’000’000
Battery Lifetime c [days] >30 (rechargeable)
Computer Interface USB
Software
Installation – SW sent by email / via download link
Operating System Windows 2000 / XP / Vista / 7 / 8
Operation Modes Autonomous / Button Triggered / Live
Operating Temperature Range Min/Max [°C] -40 / 100 (-25 / 65 for Logger)
Calibration Temperature Range Min/Max [°C] -30 / 70
Calibration Accuracy b [±%] 3
Temperature Sensor 1 / 2 Cable Length [m] 5.0 / 1.0
Heat Flux Sensor Cable Length [m] 1.5 (with connector)

a For more details consult the datasheets of the individual products.
b Sensor calibration data already loaded onto logger for simple and fast plug-and-play measurements.
c At lowest measurement frequency (2/d).

If you are interested to purchase in larger quantities, please contact info@greenTEG.com

  • – Comes with MOUNT-1214 (thermal conductive pad)

Price: from CHF 244,00

More Details
Loading Updating cart…

Measurement & Consultation Service

If you need consulting for your U-value measurement project, please  contact us. Prices for consulting services are negotiable, services are performed by internal staff of greenTEG or with external qualified partners. Send us an email and we will contact you to discuss your project. We look forward to discussing your project with you. Best regards, Dr. Holger Hendrichs | Head Building Physics



Price: CHF 0,00

More Details
Loading Updating cart…

Heat Flux Kit

Quickest and easiest solution to
monitor and analyze heat flux
and temperature difference

Features

  • – Calibrated Plug-and-Play solution
  • – Ready-to-use heat flux data with a resolution of < 0.41 W/m²
  • – Logger and live read-out
  • – Stores up to 2 million data points
  • – Battery lifetime >1 month
  • – Read-out software included
  • – USB interface
  • – For scientific and analytical measurements



Downloads
gSKIN® Heat Flux Kit Datasheet
gSKIN® Heat Flux Sensor Instruction Manual
gSKIN® Heat Flux Sensor Software Manual
gSKIN® Heat Flux Sensor Software
gSKIN® Heat Flux Measurement FAQ
Product gSKIN® KIT-1583C (calibrated)
Article Number A-161895
gSKIN® KIT includes a Sensor: gSKIN®-XM 27 9C (4.4mm x 4.4mm)
Logger: gSKIN® DLOG-4219
Mounting Tape
Sensor Calibration Method cohering to ISO8301, mean temperature of 22.5 °C
Heat Flux Range Min / Max [W/m²] ±550
Heat Flux Resolution [W/m²] <0.41
Min. Sensor Sensitivity b (S) [μV/(W/m²)] 1.5
Response Time (0-95%) [s] 0.2 c / 0.7
Logger Dimensions (l x w x h) [mm x mm x mm] 52 x 20 x 15
Measurement Frequency 50/s to 2/d
Bit Resolution [bits] 12
Data Storage Capacity [# measurements] >2’000’000
Battery Lifetime d [days] >30 (rechargeable)
Computer Interface USB
Operating System Windows 2000 / XP / Vista / 7 / 8
Operation Modes Autonomous / Button Triggered / Live
Operating Temperature Range Min/Max [°C] -50 / 150 (-25 / 65 for Logger)
Calibration Temperature Range Min/Max [°C] -30 / 70
Calibration Accuracy b [±%] 3
Heat Flux Sensor / Logger Cable Length [m] 1.5 (with connector)

a For more details consult the datasheets of the individual products.
b Sensor calibration data already loaded onto logger for simple and fast plug-and-play measurements.
c Anticipated Signal.
d At lowest measurement frequency (2/d).

If you are interested to purchase in larger quantities, please contact info@greenTEG.com

Price: CHF 889,60

More Details
Loading Updating cart…

Starter Kit

Heat Flux Sensor Starter Kit (ideal for thermal characterization of batteries)
Size: 4.4mm x 4.4mm and 10.0mm x 10.0mm
Resolves 0.4 W/m2 – 9 µW – 140 µK

Features

  • – Ultra-high resolution of thermal energies and temperature differences
  • – Low invasiveness and thickness
  • – For space resolved measurements, SOC control, life-time observation and BMS
  • – All sensors with conductive heat flux calibration cohering to ISO 8301
  • – Applications: R&D, thermal optimization, energy efficiency, industrial monitoring of thermal properties
Downloads
gSKIN® Heat Flux Sensors Datasheet
gSKIN® Heat Flux Sensors Instruction Manual
Case Study: Battery calorimetry using heat flux sensors
Case Study: Heat generation in batteries
Summary: Calorimetric measurement of batteries
Q&A: Thermal characterization of batteries using heat flux sensors
gSKIN® Starter Kit (calibrated)
Article Number A-060201
Detector Type Thermoelectric
Surface Material (Sensing Area) Aluminum
Sensing Dimensions (a x b x d) [mm x mm x mm] 4.4 x 4.4 x 0.5 and 10.0 x 10.0 x 0.5
Heat Flux Range Min / Max [kW/m²] -150 / 150
Noise Equivalent Heat Flux a per area [W/m²] / absolute [μW] 0.340 / 6.6 and 0.073 / 7.3
Heat Flux Resolution per area [W/m2] with gSKIN® DLOG b / absolute [μW] 0.41 / 7.9 and 0.09 / 9.0
Temperature Difference Resolution [μK] ~140 and ~30
Min. Sensitivity (S) [μV/(W/m²)] 1.5  and 7.0
Temperature Dependence of S [%/°C] 0.25
Response Time (0-95%) [s] 0.7
Electrical Resistance [Ohm] < 20 and < 100
Absolut Thermal Resistance [K/W] ~18.0 and ~3.5
Max. Compressive Force when clamped [kgf] < 2 and < 10
Operating Temperature Range Min/Max [°C] -50 / 150
Calibration Temperature Range Min/Max c [°C] -30 / 70
Calibration Accuracy [±%] 3
Homogeneity d [±%] 1
Linearity with Power [±%] 1
Flexprint Length [cm] 5
Flexprint Length (f) [cm] 5
Cable Length (c) [cm] 100

a Experimentally evaluated values under optimal steady state conditions.
b Guaranteed minimum heat flux resolution using the gSKIN® DLOG-4219.
c Conductive heat flux calibration cohering to the ISO8301 standard with mean temperature of 22.5 °C.
d Position dependent signal change across sensing area.

If you are interested to purchase in larger quantities, please contact info@greenTEG.com

Price: CHF 649,60

More Details
Loading Updating cart…

gSKIN®-XM

Heat Flux Sensor
Size: 4.4mm x 4.4mm
Resolves 0.41 W/m2 – 7.9 µW – 140 µK

Features

  • – Ultra-high resolution of thermal energies and temperature differences
  • – Low invasiveness and thickness
  • – Models with connector compatible with all gSKIN® DLOG Data Loggers
  • – All sensors with conductive heat flux calibration cohering to ISO 8301
  • – Applications: R&D, thermal optimization, energy efficiency, industrial monitoring of thermal properties
Downloads
gSKIN® Heat Flux Sensors Datasheet
gSKIN® Heat Flux Sensors Instruction Manual
gSKIN® XM (calibrated)
Article Number A-044336
Detector Type Thermoelectric
Surface Material (Sensing Area) Aluminum
Sensing Dimensions (a x b x d) [mm x mm x mm] 4.4 x 4.4 x 0.5
Heat Flux Range Min / Max [kW/m²] -150 / 150
Noise Equivalent Heat Flux a per area [W/m²] / absolute [μW] 0.340 / 6.6
Heat Flux Resolution per area [W/m2] with gSKIN® DLOG b / absolute [μW] 0.41 / 7.9
Temperature Difference Resolution [μK] ~140
Min. Sensitivity (S) [μV/(W/m²)] 1.5
Temperature Dependence of S [%/°C] 0.25
Response Time (0-95%) [s] 0.7
Electrical Resistance [Ohm] < 20
Absolut Thermal Resistance [K/W] 41
Max. Compressive Force when clamped [kgf] < 2
Operating Temperature Range Min/Max [°C] -50 / 150
Calibration Temperature Range Min/Max c [°C] -30 / 70
Calibration Accuracy [±%] 3
Homogeneity d [±%] 1
Linearity with Power [±%] 1
Flexprint Length [cm] 5
Flexprint Length (f) [cm] 5
Cable Length (c) [cm] 100

a Experimentally evaluated values under optimal steady state conditions.
b Guaranteed minimum heat flux resolution using the gSKIN® DLOG-4219.
c Conductive heat flux calibration cohering to the ISO8301 standard with mean temperature of 22.5 °C.
d Position dependent signal change across sensing area.

If you are interested to purchase in larger quantities, please contact info@greenTEG.com

Price: from CHF 253,30

More Details
Loading Updating cart…

gSKIN®-XP

Heat Flux Sensor
Size: 10mm x 10mm
Resolves 0.09 W/m2 – 9 µW – 30 µK

Features

  • – Ultra-high resolution of thermal energies and temperature differences
  • – Low invasiveness and thickness
  • – Models with connector compatible with all gSKIN® DLOG Data Loggers
  • – All sensors with conductive heat flux calibration cohering to ISO 8301
  • – Applications: R&D, thermal optimization, energy efficiency, industrial monitoring of thermal properties



Downloads
gSKIN® Heat Flux Sensors Datasheet
gSKIN® Heat Flux Sensors Instruction Manual
gSKIN® XP (calibrated)
Article Number A-044573
Detector Type Thermoelectric
Surface Material (Sensing Area) Aluminum
Sensing Dimensions (a x b x d) [mm x mm x mm] 10.0 x 10.0 x 0.5
Heat Flux Range Min / Max [kW/m²] -150 / 150
Noise Equivalent Heat Flux a per area [W/m²] / absolute [μW] 0.073 / 7.3
Heat Flux Resolution per area [W/m2] with gSKIN® DLOG b / absolute [μW] 0.09 / 9.0
Temperature Difference Resolution [μK] ~30
Min. Sensitivity (S) [μV/(W/m²)] 7.0
Temperature Dependence of S [%/°C] 0.25
Response Time (0-95%) [s] 0.7
Electrical Resistance [Ohm] < 100
Absolut Thermal Resistance [K/W] 7.6
Max. Compressive Force when clamped [kgf] < 10
Operating Temperature Range Min/Max [°C] -50 / 150
Calibration Temperature Range Min/Max c [°C] -30 / 70
Calibration Accuracy [±%] 3
Homogeneity d [±%] 1
Linearity with Power [±%] 1
Flexprint Length [cm] 5
Flexprint Length (f) [cm] 5
Cable Length (c) [cm] 100

a Experimentally evaluated values under optimal steady state conditions.
b Guaranteed minimum heat flux resolution using the gSKIN® DLOG-4219.
c Conductive heat flux calibration cohering to the ISO8301 standard with mean temperature of 22.5 °C.
d Position dependent signal change across sensing area.

If you are interested to purchase in larger quantities, please contact info@greenTEG.com

Price: from CHF 401,70

More Details
Loading Updating cart…

gSKIN®-XI

Heat Flux Sensor
Size: 18mm x 18mm
Resolves 0.03 W/m2 – 9 µW – 10 µK

Features

  • – Ultra-high resolution of thermal energies and temperature differences
  • – Low invasiveness and thickness
  • – Models with connector compatible with all gSKIN® DLOG Data Loggers
  • – All sensors with conductive heat flux calibration cohering to ISO 8301
  • – Applications: R&D, thermal optimization, energy efficiency, industrial monitoring of thermal properties
Downloads
gSKIN® Heat Flux Sensors Datasheet
gSKIN® Heat Flux Sensors Instruction Manual
gSKIN® XI (calibrated)
Article Number A-044628
Detector Type Thermoelectric
Surface Material (Sensing Area) Aluminum
Sensing Dimensions (a x b x d) [mm x mm x mm] 18.0 x 18.0 x 0.5
Heat Flux Range Min / Max [kW/m²] -150 / 150
Noise Equivalent Heat Flux a per area [W/m²] / absolute [μW] 0.023 / 7.5
Heat Flux Resolution per area [W/m2] with gSKIN® DLOG b / absolute [μW] 0.03 / 9.7
Temperature Difference Resolution [μK] ~10
Min. Sensitivity (S) [μV/(W/m²)] 22.0
Temperature Dependence of S [%/°C] 0.25
Response Time (0-95%) [s] 0.7
Electrical Resistance [Ohm] < 400
Absolut Thermal Resistance [K/W] 2.2
Max. Compressive Force when clamped [kgf] < 32
Operating Temperature Range Min/Max [°C] -50 / 150
Calibration Temperature Range Min/Max c [°C] -30 / 70
Calibration Accuracy [±%] 3
Homogeneity d [±%] 1
Linearity with Power [±%] 1
Flexprint Length [cm] 5
Flexprint Length (f) [cm] 5
Cable Length (c) [cm] 100

a Experimentally evaluated values under optimal steady state conditions.
b Guaranteed minimum heat flux resolution using the gSKIN® DLOG-4219.
c Conductive heat flux calibration cohering to the ISO8301 standard with mean temperature of 22.5 °C.
d Position dependent signal change across sensing area.

If you are interested to purchase in larger quantities, please contact info@greenTEG.com

Price: from CHF 637,30

More Details
Loading Updating cart…

gSKIN®-XO (Silicone)

Robust Silicone Heat Flux Sensor Size: 30mm x 30mm Resolves 0.1 W/m2 – 81 µW – 230 µK

Features

  • – Ultra-high resolution of thermal energies and temperature differences
  • – Robust sensor
  • – Models with connector compatible with all gSKIN® DLOG Data Loggers
  • – All sensors with conductive heat flux calibration cohering to ISO 8301
  • – Applications: In-situ Building monitoring, U-Value determination, environmental monitoring e.g. soil
Downloads
gSKIN® Heat Flux Sensors Datasheet
gSKIN® Heat Flux Sensors Instruction Manual


gSKIN® XO (calibrated)
Article Number A-044714
Detector Type Thermoelectric
Surface Material (Sensing Area) Aluminum
Sensing Dimensions (a x b x d) [mm x mm x mm] 30.0 x 30.0 x 2.0
Heat Flux Range Min / Max [kW/m²] -25/ 25
Noise Equivalent Heat Flux a per area [W/m²] / absolute [μW] 0.073 / 65.7
Heat Flux Resolution per area [W/m2] with gSKIN® DLOG b / absolute [μW] 0.09 / 81.0
Temperature Difference Resolution [μK] ~230
Min. Sensitivity (S) [μV/(W/m²)] 7.0
Temperature Dependence of S [%/°C] 0.25
Response Time (0-95%) [s] n/a
Electrical Resistance [Ohm] < 100
Absolut Thermal Resistance [K/W] ~2.8
Max. Compressive Force when clamped [kgf] n/a (not clampable)
Operating Temperature Range Min/Max [°C] -40 / 100
Calibration Temperature Range Min/Max c [°C] -30 / 70
Calibration Accuracy [±%] 3
Homogeneity d [±%] 1
Linearity with Power [±%] 1
Flexprint Length [cm] 5
Flexprint Length (f) [cm] 5
Cable Length (c) [cm] 100

a Experimentally evaluated values under optimal steady state conditions. b Guaranteed minimum heat flux resolution using the gSKIN® DLOG-4219. c Conductive heat flux calibration cohering to the ISO8301 standard with mean temperature of 22.5 °C. d Position dependent signal change across sensing area.

If you are interested to purchase in larger quantities, please contact info@greenTEG.com

Price: from CHF 614,10

More Details
Loading Updating cart…

gRAY B0.5-SC

Bare Die Laser Detector Size: 2mm x 2mm Sensitvity: >80mV/W

Features

  • – Very compact thermal detector
  • – Sensitive to all wavelengths from UV to MIR
  • – Powers up to 500mW
  • – Linear power response
  • – Attractive OEM pricing



Downloads
Datasheet



Product gRAY B0.5-SC (calibrated)
Article Number A-044816
Detector Type Thermopile
Spectral Range [μm] 0.19 – 15
Sensing Area (a x b) [mm x mm] 2×2
Sensor Thickness (d) [mm] 0.5
Max. Power [W] 0.5 (additional cooling necessary by heat sink)
Noise Equivalent Power a [μW] 10
Max. Average Power Density [kW/cm2] 1.5
Min. Sensitivity (Z) [mV/W] 80
Temperature Dependence of Z [%/°C] 0.125
Response Time (0-95%) [s] 0.7 b / 1.5
Linearity with Power [±%] 99.5
Operating Temperature Range Min / Max [°C] -50/100
Cooling Method conduction, convection
Electrical Connection Bottom side

a Experimentally evaluated values under optimal steady state conditions. b Anticipated signal.

If you are interested to purchase in larger quantities, please contact info@greenTEG.com

Price: CHF 0,00

More Details
Loading Updating cart…

gRAY B01-SC

Bare Die Laser Detector Size: 4.4mm x 4,4mm Sensitvity: >70mV/W

Features

  • – Highly sensitive thermal detector
  • – 100 μW to 1 W power range
  • – Sensitive to all wavelengths from UV to MIR
  • – Compact design
  • – Linear power response
  • – Attractive OEM pricing



Downloads
Datasheet



Product gRAY B01-SC (calibrated)
Article Number A-044392
Detector Type Thermopile
Spectral Range [μm] 0.19 – 15
Sensing Area (a x b) [mm x mm] 4.4 x 4.4
Sensor Thickness (d) [mm] 0.5
Max. Power [W] 1 (additional cooling necessary by heat sink)
Noise Equivalent Power a [μW] 10
Max. Average Power Density [kW/cm2] 1.5
Min. Sensitivity (Z) [mV/W] 70
Temperature Dependence of Z [%/°C] 0.125
Response Time (0-95%) [s] 0.7 b / 2.1
Homogeneity c [±%] 1
Linearity with Power [±%] 0.5
Operating Temperature Range Min / Max [°C] -50 / 150
Cooling Method conduction, convection
Electrical Connection Bottom side d

a Experimentally evaluated values under optimal steady state conditions. b Anticipated signal. c Position dependent signal change across sensing area for beam diameters down to 1.5mm. d Alternative contacting (e.g. flex prints) on request.

If you are interested to purchase in larger quantities, please contact info@greenTEG.com

Price: CHF 0,00

More Details
Loading Updating cart…

gRAY B05-SC

Bare Die Laser Detector Size: 10mm x 10mm Sensitvity: >70mV/W

Features

  • – Highly sensitive thermal detector
  • – 100 μW to 5 W power range
  • – Sensitive to all wavelengths from UV to MIR
  • – Compact design
  • – Linear power response
  • – Attractive OEM pricing



Downloads
Datasheet gRAY B05-SC



Product gRAY B05-SC (calibrated)
Article Number A-044580
Detector Type Thermopile
Spectral Range [μm] 0.19 – 15
Sensing Area (a x b) [mm x mm] 10.0 x 10.0
Sensor Thickness (d) [mm] 0.5
Max. Power [W] 5 (additional cooling necessary by heat sink)
Noise Equivalent Power a [μW] 10
Max. Average Power Density [kW/cm2] 1.5
Min. Sensitivity (Z) [mV/W] 70
Temperature Dependence of Z [%/°C] 0.125
Response Time (0-95%) [s] 0.7 b / 2.1
Homogeneity c [±%] 1
Linearity with Power [±%] 0.5
Operating Temperature Range Min / Max [°C] -50 / 150
Cooling Method conduction, convection
Electrical Connection Bottom side d

a Experimentally evaluated values under optimal steady state conditions. b Anticipated signal. c Position dependent signal change across sensing area for beam diameters down to 1.5mm. d Alternative contacting (e.g. flex prints) on request.

If you are interested to purchase in larger quantities, please contact info@greenTEG.com

Price: CHF 0,00

More Details
Loading Updating cart…
Pages: 1 2 3Next >Last »
LoadingUpdating…
